1 |
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
|
|
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
ACIR0PCB011
|
|
|
2 |
AC INPUT ASS'Y
DAC-13H,WITH FUSE10A_2EA
|
|
AC INPUT ASS'Y
DAC-13H,WITH FUSE10A_2EA
AELE0FUS002
|
|
|
2.1 |
FUSE 10A
0218010.MXP 250V,10A,4PA
|
|
FUSE 10A
0218010.MXP 250V,10A,4PA
MELE0FUS018
|
|
|
2.2 |
AC INPUT
DAC-13H
|
|
MELE0SWI015
|
|
|
3 |
FLEXIBLE LED
SMD3528 60PCS GREEN
|
|
FLEXIBLE LED
SMD3528 60PCS GREEN
AELE0LED002
|
|
|
4 |
AC MOTOR SSR PCB ASS'Y
AC MOTOR SSR
|
|
AC MOTOR SSR PCB ASS'Y
AC MOTOR SSR
AENS0PCB001
|
|
|
5 |
FND PCB ASS'Y
4870-4(STRAIGHT)
|
|
FND PCB ASS'Y
4870-4(STRAIGHT)
AFND0PCB009
|
|
|
6 |
VOLUME PCB ASS'Y
1 VOLUME
|
|
VOLUME PCB ASS'Y
1 VOLUME
AHM20PCB016
|
|
|
7 |
LED PCB ASS'Y
MULTI MAGIC 070618
|
|
LED PCB ASS'Y
MULTI MAGIC 070618
AMUM0PCB005
|
|
|
8 |
CHUTE SENSOR PCB ASS'Y
.
|
|
ASAW0PCB001
|
|
|
9 |
SMPS PANEL ASS'Y
.
|
|
ASBP0ASS017
|
|
|
9.1 |
AC MOTOR SSR PCB ASS'Y
AC MOTOR SSR
|
|
AC MOTOR SSR PCB ASS'Y
AC MOTOR SSR
AENS0PCB001
|
|
|
9.2 |
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
|
|
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
ASBP0PCB010
|
|
|
9.3 |
NOISE FILTER
ES1-F10
|
|
MELE0NOI006
|
|
|
9.4 |
POWRR SMPS
NES-150-24V(NEON=RSP_320_24)
|
|
POWRR SMPS
NES-150-24V(NEON=RSP_320_24)
MELE0SMP049
|
|
|
9.5 |
ATX POWER SUPPLY
FSP350-50TAC
|
|
ATX POWER SUPPLY
FSP350-50TAC
MELE0SMP149
|
|
|
9.6 |
TERMINAL BLOCK
250V 10P UL_CE
|
|
TERMINAL BLOCK
250V 10P UL_CE
MELE0TEB003
|
|
|
9.7 |
SMPS BKT
MEANWELL
|
|
MZZZ0MEP048
|
|
|
10 |
MEI BILL ASS'Y
|
|
ASBP0ASS051
|
|
|
10.1 |
MEI BILL AC SSR PCB ASS'Y
.
|
|
MEI BILL AC SSR PCB ASS'Y
.
ASBP0PCB015
|
|
|
10.2 |
MEI ACCEPTOR RELAY BKT-A
.
|
|
MEI ACCEPTOR RELAY BKT-A
.
MSBP0MEP225
|
|
|
10.3 |
MEI ACCEPTOR RELAY BKT-B
.
|
|
MEI ACCEPTOR RELAY BKT-B
.
MSBP0MEP226
|
|
|
11 |
MAIN PCB ASS'Y_MULTY
WITH MOMORY_TOP
|
|
MAIN PCB ASS'Y_MULTY
WITH MOMORY_TOP
ASBP0ASS059
|
|
|
11.1 |
MEMORY PCB ASS'Y
SAFARI_SPONGE BOB
|
|
MEMORY PCB ASS'Y
SAFARI_SPONGE BOB
ASAW0PCB002
|
|
|
11.2 |
TOP EXT PCB ASS'Y
SPONGE BOB PINEAPPLE
|
|
TOP EXT PCB ASS'Y
SPONGE BOB PINEAPPLE
ASBP0PCB001
|
|
|
11.3 |
MAIN PCB ASS'Y
SPONGE MULTY
|
|
MAIN PCB ASS'Y
SPONGE MULTY
ASBP0PCB012
|
|
|
12 |
MAIN PCB ASS'Y
WITH CPU_TOP
|
|
MAIN PCB ASS'Y
WITH CPU_TOP
ASBP0ASS064
|
|
|
12.1 |
MEMORY PCB ASS'Y
SAFARI_SPONGE BOB
|
|
MEMORY PCB ASS'Y
SAFARI_SPONGE BOB
ASAW0PCB002
|
|
|
12.2 |
MAIN PCB ASS'Y
V2 SAFARI_SPONGE
|
|
MAIN PCB ASS'Y
V2 SAFARI_SPONGE
ASAW0PCB003
|
|
|
12.3 |
TOP EXT PCB ASS'Y
SPONGE BOB PINEAPPLE
|
|
TOP EXT PCB ASS'Y
SPONGE BOB PINEAPPLE
ASBP0PCB001
|
|
|
13 |
BELT CONVEYOR WITH SCREW
SBP
|
|
BELT CONVEYOR WITH SCREW
SBP
ASBP0ASS074
|
|
|
14 |
HOPPER OUTLET ASS'Y
V3
|
|
ASBP0ASS089
|
|
|
14.1 |
MICRO SWITCH-S
GSMS5_41TLA(구3142)
|
|
MICRO SWITCH-S
GSMS5_41TLA(구3142)
MELE0MIC003
|
|
|
14.2 |
COUNTER HOPPER OUTLET GUIDE
.
|
|
COUNTER HOPPER OUTLET GUIDE
.
MSBP0MEP067
|
|
|
14.3 |
COUNTER HOPPER OUTLET GUIDE SUB
.
|
|
COUNTER HOPPER OUTLET GUIDE SUB
.
MSBP0MEP068
|
|
|
14.4 |
COUNTER HOPPER RINK BKT-A
.
|
|
COUNTER HOPPER RINK BKT-A
.
MSBP0MEP162
|
|
|
14.5 |
COUNTER HOPPER SENSOR BKT
.
|
|
COUNTER HOPPER SENSOR BKT
.
MSBP0MEP179
|
|
|
14.6 |
COIN CUHUTE RINK SHAFT A
.
|
|
COIN CUHUTE RINK SHAFT A
.
MSBP0PRO024
|
|
|
14.7 |
COUNTER HOPPER OUTLET RINK SHAFT
.
|
|
COUNTER HOPPER OUTLET RINK SHAFT
.
MSBP0PRO034
|
|
|
14.8 |
MOTOR
KGC-3429-075-1/210_31RPM
|
|
MOTOR
KGC-3429-075-1/210_31RPM
MZZZ0MOT088
|
|
|
15 |
BONUS FND PCB ASS'Y
SND1817 3자리
|
|
BONUS FND PCB ASS'Y
SND1817 3자리
ASBP0PCB003
|
|
|
16 |
COIN CHUTE PCB ASS'Y
SBP BGR
|
|
COIN CHUTE PCB ASS'Y
SBP BGR
ASBP0PCB004
|
|
|
17 |
BILLBOARD LED 10 PCB ASS'Y
LED 10EA
|
|
BILLBOARD LED 10 PCB ASS'Y
LED 10EA
ASBP0PCB005
|
|
|
18 |
WHEEL LED PCB ASS'Y
SBP BGR
|
|
WHEEL LED PCB ASS'Y
SBP BGR
ASBP0PCB006
|
|
|
19 |
UPDATE WHEEL LED PCB ASS'Y
SBP BGR
|
|
UPDATE WHEEL LED PCB ASS'Y
SBP BGR
ASBP0PCB007
|
|
|
20 |
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
|
|
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
ASBP0PCB010
|
|
|
21 |
NEW SENSOR PCB ASS'Y
SBP 20160624
|
|
NEW SENSOR PCB ASS'Y
SBP 20160624
ASBP0PCB016
|
|
|
22 |
CARD ASS'Y_RFID_SBP2
150EA 1BOX
|
|
CARD ASS'Y_RFID_SBP2
150EA 1BOX
ASBP0RFC002
|
|
|
23 |
CARD ASS'Y_EUR
SET 154_WITH SPECIAL
|
|
CARD ASS'Y_EUR
SET 154_WITH SPECIAL
ASBP0ZZZ003
|
|
|
24 |
CARD DISPENSER SETTING JIG
SBP_DC_WWE
|
|
CARD DISPENSER SETTING JIG
SBP_DC_WWE
AZZZ0ACP002
|
|
|
25 |
COIN BOX ASS WITH 6001
SMALL 200*198*107
|
|
COIN BOX ASS WITH 6001
SMALL 200*198*107
AZZZ0ASS002
|
|
|
25.1 |
COIN BOX SMALL
200*198*107 BLACK
|
|
COIN BOX SMALL
200*198*107 BLACK
MDRE0PLA007
|
|
|
25.2 |
KEY ASS'Y 6001
6001 키뭉치만
|
|
MZZZ0KEY075
|
|
|
26 |
FRONT ROLLER V1
BASIC DC4_SBP_DC2
|
|
FRONT ROLLER V1
BASIC DC4_SBP_DC2
AZZZ0ASS016
|
|
|
26.1 |
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
|
|
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
ACIR0PCB011
|
|
|
26.2 |
FRONT ROLLER MEP13종
|
|
ADCC0ASS052
|
|
|
26.2.1 |
FRONT ROLLER BKT-A
.
|
|
MSBP0MEP058
|
|
|
26.2.2 |
FRONT ROLLER BKT-G
.
|
|
MSBP0MEP061
|
|
|
26.2.3 |
FRONT ROLLER ENCONDER BKT-B
.
|
|
FRONT ROLLER ENCONDER BKT-B
.
MSBP0MEP063
|
|
|
26.2.4 |
FRONT ROLLER MOTOR BKT
.
|
|
MSBP0MEP064
|
|
|
26.3 |
FRONT PRO PART 5종
MSBP0PRO10,11,12,13,14
|
|
FRONT PRO PART 5종
MSBP0PRO10,11,12,13,14
ASBP0PAR008
|
|
|
26.3.1 |
MEDAL ROLLER-B1 ASS'Y
MAV20PRO087,088,089
|
|
MEDAL ROLLER-B1 ASS'Y
MAV20PRO087,088,089
AAV20PRO009
|
|
|
26.3.2 |
FRONT ROLLER ENCONDER BKT-C
.
|
|
FRONT ROLLER ENCONDER BKT-C
.
MSBP0MEP239
|
|
|
26.3.3 |
FRONT ROLLER-A
.
|
|
MSBP0PRO010
|
|
|
26.3.4 |
CHANGE_AAV20PRO009+MSBP0MEP239
|
|
CHANGE_AAV20PRO009+MSBP0MEP239
MSBP0PRO011
|
|
|
26.3.5 |
FRONT ROLLER-C
.
|
|
MSBP0PRO012
|
|
|
26.3.6 |
FRONT ROLLER-D
.
|
|
MSBP0PRO013
|
|
|
26.3.7 |
FRONT ROLLER-F
.
|
|
MSBP0PRO014
|
|
|
26.4 |
FRONT ROLLER GUIDE MOLD-L
.
|
|
FRONT ROLLER GUIDE MOLD-L
.
MDCC0PLA007
|
|
|
26.5 |
FRONT ROLLER GUIDE MOLD-R
.
|
|
FRONT ROLLER GUIDE MOLD-R
.
MDCC0PLA008
|
|
|
26.6 |
TIMMING BELT TENSION ROLLER
.
|
|
TIMMING BELT TENSION ROLLER
.
MSBP0PRO017
|
|
|
26.7 |
BEARING
F606ZZ
|
|
MZZZ0BEA073
|
|
|
26.8 |
BEARING
F689ZZ JAPAN
|
|
MZZZ0BEA109
|
|
|
26.9 |
TIMMING BELT
170MXL,W4.8 URETAN
|
|
TIMMING BELT
170MXL,W4.8 URETAN
MZZZ0BEL020
|
|
|
26.10 |
BELT CONVEYOR
우레탄1.4T*W100*L320 GREEN(4M홀)
|
|
BELT CONVEYOR
우레탄1.4T*W100*L320 GREEN(4M홀)
MZZZ0BEL067
|
|
|
26.11 |
GEAR
20M MODULE
|
|
MZZZ0ELH042
|
|
|
26.12 |
TIMMING PULLEY
MXL-29,분말야금
|
|
TIMMING PULLEY
MXL-29,분말야금
MZZZ0MOL002
|
|
|
26.13 |
MOTOR
KGV-0060-ND3657U2
|
|
MZZZ0MOT087
|
|
|
26.14 |
FRONT ROLLER RUBBER HOUSING-A
실리콘
|
|
FRONT ROLLER RUBBER HOUSING-A
실리콘
MZZZ0RUB019
|
|
|
26.15 |
FRONT ROLLER RUBBER HOUSING-B
실리콘
|
|
FRONT ROLLER RUBBER HOUSING-B
실리콘
MZZZ0RUB020
|
|
|
27 |
FRONT ROLLER V2
BASIC DC4_SBP_DC2
|
|
FRONT ROLLER V2
BASIC DC4_SBP_DC2
AZZZ0ASS075
|
|
|
27.1 |
MEDAL ROLLER-C ASS'Y
MAV20PRO003,62
|
|
MEDAL ROLLER-C ASS'Y
MAV20PRO003,62
AAV20PRO005
|
|
|
27.2 |
MEDAL ROLLER-B1 ASS'Y
MAV20PRO087,088,089
|
|
MEDAL ROLLER-B1 ASS'Y
MAV20PRO087,088,089
AAV20PRO009
|
|
|
27.3 |
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
|
|
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
ACIR0PCB011
|
|
|
27.4 |
COUPLING CR050 ASS'Y
8*8_M5_TAB120_M3_18.4
|
|
COUPLING CR050 ASS'Y
8*8_M5_TAB120_M3_18.4
AZZZ0COP003
|
|
|
27.5 |
FRONT ROLLER GUIDE MOLD-L
.
|
|
FRONT ROLLER GUIDE MOLD-L
.
MDCC0PLA007
|
|
|
27.6 |
FRONT ROLLER GUIDE MOLD-R
.
|
|
FRONT ROLLER GUIDE MOLD-R
.
MDCC0PLA008
|
|
|
27.7 |
FRONT ROLLER SHAFT DUSH
.
|
|
FRONT ROLLER SHAFT DUSH
.
MSBP0ACR056
|
|
|
27.8 |
BEARING
F606ZZ
|
|
MZZZ0BEA073
|
|
|
27.9 |
BEARING
F688ZZ
|
|
MZZZ0BEA076
|
|
|
27.10 |
BEARING
F689ZZ JAPAN
|
|
MZZZ0BEA109
|
|
|
27.11 |
BEARING
F605ZZ
|
|
MZZZ0BEA141
|
|
|
27.12 |
TIMMING BELT
146XL , W10
|
|
MZZZ0BEL056
|
|
|
27.13 |
GEAR
20M MODULE
|
|
MZZZ0ELH042
|
|
|
27.14 |
MOTOR
KGV2-0060-ND3657U2 , R-TYPE
|
|
MOTOR
KGV2-0060-ND3657U2 , R-TYPE
MZZZ0MOT168
|
|
|
27.15 |
FRONT ROLLER RUBBER HOUSING-A
실리콘
|
|
FRONT ROLLER RUBBER HOUSING-A
실리콘
MZZZ0RUB019
|
|
|
27.16 |
FRONT ROLLER RUBBER HOUSING-B
실리콘
|
|
FRONT ROLLER RUBBER HOUSING-B
실리콘
MZZZ0RUB020
|
|
|
28 |
A_CARD DISPENSOR_COMMON A
DC SBP SPP2P RED_ PCB R
|
|
A_CARD DISPENSOR_COMMON A
DC SBP SPP2P RED_ PCB R
AZZZ0ASS079
|
|
|
28.1 |
CARD DISPENSOR I/O PCB ASS'Y
CARD DISPENSOR
|
|
CARD DISPENSOR I/O PCB ASS'Y
CARD DISPENSOR
ASBP0PCB008
|
|
|
28.2 |
PHOTO INT-1 PCB ASS'Y
ANGLE TYPE
|
|
PHOTO INT-1 PCB ASS'Y
ANGLE TYPE
AZZZ0PCB103
|
|
|
28.3 |
TIMMING BELT TENSION ROLLER
.
|
|
TIMMING BELT TENSION ROLLER
.
MSBP0PRO017
|
|
|
28.4 |
BEARING
F686ZZ
|
|
MZZZ0BEA094
|
|
|
28.5 |
DU BUSH
0608DU
|
|
MZZZ0BEA096
|
|
|
28.6 |
TIMMING BELT
52MXL,W4.8 RUBBER
|
|
TIMMING BELT
52MXL,W4.8 RUBBER
MZZZ0BEL018
|
|
|
28.7 |
TIMMING BELT
147MXL,W4.8 RUBBER
|
|
TIMMING BELT
147MXL,W4.8 RUBBER
MZZZ0BEL019
|
|
|
28.8 |
MOTOR
KGC-040-3429C
|
|
MZZZ0MOT089
|
|
|
28.9 |
TIMMING PULLEY
MXL-47
|
|
MZZZ0PLA039
|
|
|
28.10 |
TIMMING PULLEY
MXL-29
|
|
MZZZ0PLA040
|
|
|
28.11 |
CARD OUTLET GUIDE BLOCK
ABS
|
|
CARD OUTLET GUIDE BLOCK
ABS
MZZZ0PLA042
|
|
|
28.12 |
PCB SUPPORT
M 5MM
|
|
MZZZ0PLA057
|
|
|
28.13 |
CARD DISPENSER RUBBER HOUSING-A
|
|
CARD DISPENSER RUBBER HOUSING-A
MZZZ0RUB017
|
|
|
28.14 |
CARD DISPENSER RUBBER HOUSING-B
실리콘
|
|
CARD DISPENSER RUBBER HOUSING-B
실리콘
MZZZ0RUB018
|
|
|
29 |
BUTTON ASS'Y
CL-2020 65 WITH LED
|
|
BUTTON ASS'Y
CL-2020 65 WITH LED
AZZZ0BUT009
|
|
|
29.1 |
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
|
|
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
MELE0MIC013
|
|
|
29.2 |
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
|
|
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
MZZZ0BUT101
|
|
|
29.3 |
HOLDER ASS'Y
LED포함
|
|
MZZZ0BUT103
|
|
|
30 |
ELEVATOR ASS'Y
SBP FRONT WITH RAIL
|
|
ELEVATOR ASS'Y
SBP FRONT WITH RAIL
AZZZ0ELH021
|
|
|
30.1 |
ELEVATOR HOPPER BODY ASS'Y
SBP FRONT
|
|
ELEVATOR HOPPER BODY ASS'Y
SBP FRONT
AZZZ0ELH016
|
|
|
30.1.1 |
ELEVATOR HOPPER BODY ASS'Y
A TYPE_COMMON BODY
|
|
ELEVATOR HOPPER BODY ASS'Y
A TYPE_COMMON BODY
AZZZ0ELH001
|
|
|
30.1.1.1 |
HOPPER DISK ASS'Y
.
|
|
AZZZ0ASS008
|
|
|
30.1.1.2 |
ELEVATOR HOPPER BODY PRESS
A TYPE
|
|
ELEVATOR HOPPER BODY PRESS
A TYPE
AZZZ0ELH005
|
|
|
30.1.1.2.1 |
COIN BOWL BOX
AV1 AV2
|
|
AZZZ0ASS091
|
|
|
30.1.1.2.1.1 |
COIN BOWL BOX
.
|
|
MZZZ0ELH030
|
|
|
30.1.1.2.2 |
OUTLET GUIDE ASS'Y
.
|
|
AZZZ0ASS092
|
|
|
30.1.1.2.3 |
MEDAL TENSION GUIDE BLOCK ASS'Y
MZZZ0ELH008+MZZZ0ELH013
|
|
MEDAL TENSION GUIDE BLOCK ASS'Y
MZZZ0ELH008+MZZZ0ELH013
AZZZ0ELH026
|
|
|
30.1.1.2.3.1 |
MEDAL TENSION GUIDE BLOCK
.
|
|
MEDAL TENSION GUIDE BLOCK
.
MZZZ0ELH008
|
|
|
30.1.1.2.3.2 |
RAIL TENSION GUIDE-A
.
|
|
MZZZ0ELH013
|
|
|
30.1.1.2.4 |
BEARING
685ZZ
|
|
MZZZ0BEA107
|
|
|
30.1.1.2.5 |
BODY FRAME OUTLET COVER
.
|
|
BODY FRAME OUTLET COVER
.
MZZZ0ELH003
|
|
|
30.1.1.2.6 |
COIN GUIDE PLATE
.
|
|
MZZZ0ELH007
|
|
|
30.1.1.2.7 |
MEDAL TENSION GUIDE BLOCK
.
|
|
MEDAL TENSION GUIDE BLOCK
.
MZZZ0ELH008
|
|
|
30.1.1.2.8 |
OUTLET GUIDE RAIL COVER-A
.
|
|
OUTLET GUIDE RAIL COVER-A
.
MZZZ0ELH010
|
|
|
30.1.1.2.9 |
OUTLET GUIDE RAIL COVER-B
.
|
|
OUTLET GUIDE RAIL COVER-B
.
MZZZ0ELH011
|
|
|
30.1.1.2.10 |
OUTLET GUIDE RAIL-A
.
|
|
MZZZ0ELH012
|
|
|
30.1.1.2.11 |
RAIL TENSION GUIDE-A
.
|
|
MZZZ0ELH013
|
|
|
30.1.1.2.12 |
COIN BOWL BAFFLE BAR
8MM X L130 _PVC환봉
|
|
COIN BOWL BAFFLE BAR
8MM X L130 _PVC환봉
MZZZ0ELH038
|
|
|
30.1.1.2.13 |
COIN GUIDE PLATE
MZZZ0ELH007-01
|
|
COIN GUIDE PLATE
MZZZ0ELH007-01
MZZZ0ELH049
|
|
|
30.1.1.2.14 |
BEARING GUIDE PIN
CHIP HOPPER
|
|
BEARING GUIDE PIN
CHIP HOPPER
MZZZ0HOP033
|
|
|
30.1.1.3 |
ELEVATOR HOPPER PCB ASS'Y
COMMON_NUVOTON
|
|
ELEVATOR HOPPER PCB ASS'Y
COMMON_NUVOTON
AZZZ0PCB143
|
|
|
30.1.1.4 |
COIN BOWL BOX BASE SUPT
.
|
|
COIN BOWL BOX BASE SUPT
.
MZZZ0ELH005
|
|
|
30.1.1.5 |
OUTLET GUIDE BLOCK
.
|
|
MZZZ0ELH009
|
|
|
30.1.1.6 |
HOPPER PCB COVER
.
|
|
MZZZ0ELH029
|
|
|
30.1.1.7 |
COIN BOWL BOX
.
|
|
MZZZ0ELH030
|
|
|
30.1.1.8 |
HOPPER RAIL BALL GUIDE
.
|
|
MZZZ0ELH031
|
|
|
30.1.1.9 |
HOPPER DISK FILM
.
|
|
MZZZ0ELH032
|
|
|
30.1.1.10 |
MOTOR COVER
.
|
|
MZZZ0ELH033
|
|
|
30.1.1.11 |
MOTOR ELEVATOR HOPPER
KGV-0060-ND4266X2
|
|
MOTOR ELEVATOR HOPPER
KGV-0060-ND4266X2
MZZZ0ELH040
|
|
|
30.1.1.12 |
COIN BLOCK SPRING
SUS-0.7MM
|
|
COIN BLOCK SPRING
SUS-0.7MM
MZZZ0ELH045
|
|
|
30.1.2 |
ELEVATOR EARTH BKT BASE
.
|
|
ELEVATOR EARTH BKT BASE
.
MSBP0ACR041
|
|
|
31 |
ELEVATOR ASS'Y
SBP REAL WITH RAIL
|
|
ELEVATOR ASS'Y
SBP REAL WITH RAIL
AZZZ0ELH022
|
|
|
31.1.2 |
ELEVATOR HOPPER BODY ASS'Y
SBP REAR
|
|
ELEVATOR HOPPER BODY ASS'Y
SBP REAR
AZZZ0ELH009
|
|
|
31.1.1 |
ELEVATOR HOPPER BODY ASS'Y
A TYPE_COMMON BODY
|
|
ELEVATOR HOPPER BODY ASS'Y
A TYPE_COMMON BODY
AZZZ0ELH001
|
|
|
31.1.1.1 |
HOPPER DISK ASS'Y
.
|
|
AZZZ0ASS008
|
|
|
31.1.1.2 |
ELEVATOR HOPPER BODY PRESS
A TYPE
|
|
ELEVATOR HOPPER BODY PRESS
A TYPE
AZZZ0ELH005
|
|
|
31.1.1.2.1 |
COIN BOWL BOX
AV1 AV2
|
|
AZZZ0ASS091
|
|
|
31.1.1.2.1.1 |
COIN BOWL BOX
.
|
|
MZZZ0ELH030
|
|
|
31.1.1.2.2 |
OUTLET GUIDE ASS'Y
.
|
|
AZZZ0ASS092
|
|
|
31.1.1.2.3 |
MEDAL TENSION GUIDE BLOCK ASS'Y
MZZZ0ELH008+MZZZ0ELH013
|
|
MEDAL TENSION GUIDE BLOCK ASS'Y
MZZZ0ELH008+MZZZ0ELH013
AZZZ0ELH026
|
|
|
31.1.1.2.3.1 |
MEDAL TENSION GUIDE BLOCK
.
|
|
MEDAL TENSION GUIDE BLOCK
.
MZZZ0ELH008
|
|
|
31.1.1.2.3.2 |
RAIL TENSION GUIDE-A
.
|
|
MZZZ0ELH013
|
|
|
31.1.1.2.4 |
BEARING
685ZZ
|
|
MZZZ0BEA107
|
|
|
31.1.1.2.5 |
BODY FRAME OUTLET COVER
.
|
|
BODY FRAME OUTLET COVER
.
MZZZ0ELH003
|
|
|
31.1.1.2.6 |
COIN GUIDE PLATE
.
|
|
MZZZ0ELH007
|
|
|
31.1.1.2.7 |
MEDAL TENSION GUIDE BLOCK
.
|
|
MEDAL TENSION GUIDE BLOCK
.
MZZZ0ELH008
|
|
|
31.1.1.2.8 |
OUTLET GUIDE RAIL COVER-A
.
|
|
OUTLET GUIDE RAIL COVER-A
.
MZZZ0ELH010
|
|
|
31.1.1.2.9 |
OUTLET GUIDE RAIL COVER-B
.
|
|
OUTLET GUIDE RAIL COVER-B
.
MZZZ0ELH011
|
|
|
31.1.1.2.10 |
OUTLET GUIDE RAIL-A
.
|
|
MZZZ0ELH012
|
|
|
31.1.1.2.11 |
RAIL TENSION GUIDE-A
.
|
|
MZZZ0ELH013
|
|
|
31.1.1.2.12 |
COIN BOWL BAFFLE BAR
8MM X L130 _PVC환봉
|
|
COIN BOWL BAFFLE BAR
8MM X L130 _PVC환봉
MZZZ0ELH038
|
|
|
31.1.1.2.13 |
COIN GUIDE PLATE
MZZZ0ELH007-01
|
|
COIN GUIDE PLATE
MZZZ0ELH007-01
MZZZ0ELH049
|
|
|
31.1.1.2.14 |
BEARING GUIDE PIN
CHIP HOPPER
|
|
BEARING GUIDE PIN
CHIP HOPPER
MZZZ0HOP033
|
|
|
31.1.1.3 |
ELEVATOR HOPPER PCB ASS'Y
COMMON_NUVOTON
|
|
ELEVATOR HOPPER PCB ASS'Y
COMMON_NUVOTON
AZZZ0PCB143
|
|
|
31.1.1.4 |
COIN BOWL BOX BASE SUPT
.
|
|
COIN BOWL BOX BASE SUPT
.
MZZZ0ELH005
|
|
|
31.1.1.5 |
OUTLET GUIDE BLOCK
.
|
|
MZZZ0ELH009
|
|
|
31.1.1.6 |
HOPPER PCB COVER
.
|
|
MZZZ0ELH029
|
|
|
31.1.1.7 |
COIN BOWL BOX
.
|
|
MZZZ0ELH030
|
|
|
31.1.1.8 |
HOPPER RAIL BALL GUIDE
.
|
|
MZZZ0ELH031
|
|
|
31.1.1.9 |
HOPPER DISK FILM
.
|
|
MZZZ0ELH032
|
|
|
31.1.1.10 |
MOTOR COVER
.
|
|
MZZZ0ELH033
|
|
|
31.1.1.11 |
MOTOR ELEVATOR HOPPER
KGV-0060-ND4266X2
|
|
MOTOR ELEVATOR HOPPER
KGV-0060-ND4266X2
MZZZ0ELH040
|
|
|
31.1.1.12 |
COIN BLOCK SPRING
SUS-0.7MM
|
|
COIN BLOCK SPRING
SUS-0.7MM
MZZZ0ELH045
|
|
|
31.1.2 |
ELEVATOR EARTH BKT-B
.
|
|
MSBP0MEP167
|
|
|
32 |
ELEVATOR ASS'Y OLD TYPE
YADA HOPPER
|
|
ELEVATOR ASS'Y OLD TYPE
YADA HOPPER
AZZZ0HOP022
|
|
|
32.1.2 |
REAR ELEVATOR HOPPER RAIL-A
.
|
|
REAR ELEVATOR HOPPER RAIL-A
.
MSBP0MEP050
|
|
|
32.2.2 |
REAR ELEVATOR HOPPER RAIL-B
.
|
|
REAR ELEVATOR HOPPER RAIL-B
.
MSBP0MEP051
|
|
|
32.3.2 |
ELEVATOR EARTH BKT-B
.
|
|
MSBP0MEP167
|
|
|
32.4.2 |
ELEVATOR SPRING
REAR
|
|
MSBP0SPR002
|
|
|
32.5.2 |
SENSOR
YADA
|
|
MZZZ0HOP024
|
|
|
32.6.2 |
HOPPER PCB
YADA WITH COVER
|
|
HOPPER PCB
YADA WITH COVER
MZZZ0HOP025
|
|
|
32.7.2 |
MAIN BODY COVER
YADA
|
|
MZZZ0HOP051
|
|
|
32.8.2 |
DISK COVER
YADA
|
|
MZZZ0HOP052
|
|
|
32.9.2 |
COIN GUIDE PIN BKT
YADA
|
|
MZZZ0HOP053
|
|
|
32.10.2 |
COIN GUIDE PIN BKT COVER
YADA
|
|
COIN GUIDE PIN BKT COVER
YADA
MZZZ0HOP054
|
|
|
32.11.2 |
MOTOR
KGV-0060-ND4266X2-01 YADA
|
|
MOTOR
KGV-0060-ND4266X2-01 YADA
MZZZ0MOT098
|
|
|
33 |
HOPPER MACHINE V2 OLD
20160211
|
|
HOPPER MACHINE V2 OLD
20160211
AZZZ0HOP023
|
|
|
33.1.2 |
HOPPER PARTS
201410
|
|
AZZZ0HOP018
|
|
|
33.1.1 |
COIN GUIDE PLATE-B
AMHP-016A
|
|
COIN GUIDE PLATE-B
AMHP-016A
MZZZ0HOP010
|
|
|
33.1.2 |
CYLINDER LEVER
AMHP-015A SUS304
|
|
CYLINDER LEVER
AMHP-015A SUS304
MZZZ0PRE017
|
|
|
33.1.2.1 |
BEARING
MR105ZZ_JAPAN
|
|
MZZZ0BEA082
|
|
|
33.1.3 |
ELLIPTICAL BASE
AMHP-002A SPCC,ZN-PLATED
|
|
ELLIPTICAL BASE
AMHP-002A SPCC,ZN-PLATED
MZZZ0PRE018
|
|
|
33.1.4 |
COIN GUIDE PLATE
AMHP-017A
|
|
COIN GUIDE PLATE
AMHP-017A
MZZZ0PRE037
|
|
|
33.2 |
MOTOR DC24V ASS WITH BKT
KGV2-0070-4266X2-01 OLD C_HOPPER용
|
|
MOTOR DC24V ASS WITH BKT
KGV2-0070-4266X2-01 OLD C_HOPPER용
AZZZ0MOT003
|
|
|
33.2.1 |
NEW TYPE SENSOR BRK
CYLINDER LEVER ASS
|
|
NEW TYPE SENSOR BRK
CYLINDER LEVER ASS
AZZZ0HOP041
|
|
|
33.2.1.1 |
LEVER SHAFT
.
|
|
MZZZ0HOP074
|
|
|
33.2.2 |
MAMUAL
C_H 신형모터설명
|
|
MZZZ0MAN013
|
|
|
33.2.3 |
MOTOR DC24V C_HOPPER
KGV2-0070-4266X2-01
|
|
MOTOR DC24V C_HOPPER
KGV2-0070-4266X2-01
MZZZ0MOT136
|
|
|
33.3 |
PHOTO SENSOR
LG-217L3
|
|
MELE0PHO007
|
|
|
33.4 |
HOPPER CASE
PC
|
|
MPUS0PLA004
|
|
|
33.5 |
BEARING
MR105ZZ_JAPAN
|
|
MZZZ0BEA082
|
|
|
33.6 |
HOPPER DISK
가공 디스크
|
|
MZZZ0PRO038
|
|
|
33.7 |
SPRING
AMHP-014A
|
|
MZZZ0SPR002
|
|
|
34 |
HOPPER MACHINE V3
AM-CH2 SBP
|
|
HOPPER MACHINE V3
AM-CH2 SBP
AZZZ0HOP034
|
|
|
34.1 |
HOPPER MACHINE 공용
.
|
|
AZZZ0PAR053
|
|
|
34.1.1 |
SENSOR LINK BKT PART
.
|
|
AHOP0ASS001
|
|
|
34.1.1.1 |
SENSOR LINK BKT ASS'Y
.
|
|
AHOP0ASS005
|
|
|
34.1.1.2 |
SENSOR LINK BKT BEARING PIN
.
|
|
SENSOR LINK BKT BEARING PIN
.
MHOP0PRO002
|
|
|
34.1.1.3 |
BEARING
693ZZ
|
|
MZZZ0BEA012
|
|
|
34.1.2 |
COIN SHOOTER BKT PART
.
|
|
AHOP0ASS002
|
|
|
34.1.2.1 |
COIN SHOOTER ASS
.
|
|
AHOP0ASS006
|
|
|
34.1.2.2 |
COIN SHOOTER SHAFT
.
|
|
MHOP0PRO004
|
|
|
34.1.2.3 |
COIN SHOOTER BEARING PIN
.
|
|
COIN SHOOTER BEARING PIN
.
MHOP0PRO005
|
|
|
34.1.2.4 |
BEARING
MR105ZZ_JAPAN
|
|
MZZZ0BEA082
|
|
|
34.1.3 |
HOPPER DISK PART
.
|
|
AHOP0MEP002
|
|
|
34.1.3.1 |
HOPPER DISK BASE BKT
.
|
|
MHOP0MEP001
|
|
|
34.1.3.2 |
HOPPER DISK MOLD
POM
|
|
MHOP0MOL002
|
|
|
34.1.4 |
MAIN PLATE PART
.
|
|
AHOP0MEP003
|
|
|
34.1.5 |
PHOTO SENSOR
LG-217L3
|
|
MELE0PHO007
|
|
|
34.1.6 |
COUNTER HOPPER BASE COVER
.
|
|
COUNTER HOPPER BASE COVER
.
MHOP0ACR001
|
|
|
34.1.7 |
MAIN PLATE TOP COVER
.
|
|
MHOP0MEP004
|
|
|
34.1.8 |
SENSOR BKT
.
|
|
MHOP0MEP007
|
|
|
34.1.9 |
SHOOTER LINK BKT GUIDE
.
|
|
MHOP0MEP008
|
|
|
34.1.10 |
HOPPER BASE SIDE BKT_MIR
.
|
|
HOPPER BASE SIDE BKT_MIR
.
MHOP0MEP009
|
|
|
34.1.11 |
HOPPER BASE SIDE BKT
.
|
|
MHOP0MEP010
|
|
|
34.1.12 |
HOPPER COIN BOWL BOX NEW
PC ABS , 흑색
|
|
HOPPER COIN BOWL BOX NEW
PC ABS , 흑색
MHOP0MOL001
|
|
|
34.1.13 |
MOTOR
KGV-0105-ND4266 X2 , SSF
|
|
MOTOR
KGV-0105-ND4266 X2 , SSF
MHOP0MOT001
|
|
|
34.1.14 |
SENSOR LINK BKT SHAFT
.
|
|
MHOP0PRO003
|
|
|
34.1.15 |
CUSHION RUBBER SHAFT
.
|
|
MHOP0PRO006
|
|
|
34.1.16 |
SPRING-1
.
|
|
MHOP0SPR002
|
|
|
34.1.17 |
WAVE WASHER
내경Φ6 _ WW-6
|
|
MHOP0ZZZ001
|
|
|
34.1.18 |
CUSHION RUBBER
내경8*외경12
|
|
MHOP0ZZZ002
|
|
|
34.1.19 |
PACKING RING
AMHP-003A PVC-투명
|
|
PACKING RING
AMHP-003A PVC-투명
MZZZ0PRE022
|
|
|
35 |
COIN MEDAL_NI
24.8 BRASS SILVER
|
|
COIN MEDAL_NI
24.8 BRASS SILVER
AZZZ0MED001
|
|
|
36 |
SETUP LCD PCB ASS'Y
UNISYSTECH
|
|
SETUP LCD PCB ASS'Y
UNISYSTECH
AZZZ0PCB113
|
|
|
37 |
LED BAR 12V ASS'Y
460MM
|
|
AZZZ0PCB124
|
|
|
38 |
LED BAR 12V ASS'Y
910MM
|
|
AZZZ0PCB128
|
|
|
39 |
L6205 V2 HOPPER PCB ASS'Y
공용
|
|
L6205 V2 HOPPER PCB ASS'Y
공용
AZZZ0PCB172
|
|
|
40 |
RGB_BUTTON_LED PCB ASS'Y V2
1K
|
|
RGB_BUTTON_LED PCB ASS'Y V2
1K
AZZZ0PCB209
|
|
|
41 |
SIDE PAYOUT GUIDE MOLD
.
|
|
MDCC0PLA010
|
|
|
42 |
LED STICK BAR BRK
12MM 90도
|
|
LED STICK BAR BRK
12MM 90도
MELE0000022
|
|
|
43 |
FERRITE CORE
RU(TU)1335
|
|
MELE0FER001
|
|
|
44 |
NOISE FILTER
ES1-F10
|
|
MELE0NOI006
|
|
|
45 |
POWRR SMPS
NES-150-24V(NEON=RSP_320_24)
|
|
POWRR SMPS
NES-150-24V(NEON=RSP_320_24)
MELE0SMP049
|
|
|
46 |
ATX POWER SUPPLY
FSP350-50TAC
|
|
ATX POWER SUPPLY
FSP350-50TAC
MELE0SMP149
|
|
|
47 |
TARGET MOLD
ABS
|
|
MSAW0PLA001
|
|
|
48 |
GEAR HEAD
K6G90C_AC MOTOR
|
|
GEAR HEAD
K6G90C_AC MOTOR
MSAW0ZZZ008
|
|
|
49 |
CARD HEAVY PUSH BKT
.
|
|
MSBP0MEP023
|
|
|
50 |
PUSHER BODY COIN BAFFLE
ACETAL
|
|
PUSHER BODY COIN BAFFLE
ACETAL
MSBP0PRO001
|
|
|
51 |
PUSHER BEARING
.
|
|
MSBP0PRO002
|
|
|
52 |
WHEEL SHAFT TIMMING PULLY
14XL-050-6F
|
|
WHEEL SHAFT TIMMING PULLY
14XL-050-6F
MSBP0PRO004
|
|
|
53 |
WHEEL MOTOR TIMMING PULLY
36XL-050-6F
|
|
WHEEL MOTOR TIMMING PULLY
36XL-050-6F
MSBP0PRO005
|
|
|
54 |
CARD ROLLER SHAFT-A
.
|
|
MSBP0PRO006
|
|
|
55 |
CARD ROLLER SHAFT-B
.
|
|
MSBP0PRO007
|
|
|
56 |
CARD ROLLER SHAFT-C
.
|
|
MSBP0PRO008
|
|
|
57 |
BEARING GUIDE SHAFT
.
|
|
MSBP0PRO009
|
|
|
58 |
FRONT ROLLER-A
.
|
|
MSBP0PRO010
|
|
|
59 |
CHANGE_AAV20PRO009+MSBP0MEP239
|
|
CHANGE_AAV20PRO009+MSBP0MEP239
MSBP0PRO011
|
|
|
60 |
FRONT ROLLER-C
.
|
|
MSBP0PRO012
|
|
|
61 |
FRONT ROLLER-D
.
|
|
MSBP0PRO013
|
|
|
62 |
FRONT ROLLER-F
.
|
|
MSBP0PRO014
|
|
|
63 |
COUPLING CR050
CODE CHANGE AZZZ0COP003
|
|
COUPLING CR050
CODE CHANGE AZZZ0COP003
MSBP0PRO015
|
|
|
64 |
TARGET PIN
.
|
|
MSBP0PRO016
|
|
|
65 |
BILLBOARD POP SUPT-A
.
|
|
MSBP0PRO018
|
|
|
66 |
BILLBOARD POP SUPT-B
.
|
|
MSBP0PRO019
|
|
|
67 |
BILLBOARD POP SUPT-C
.
|
|
MSBP0PRO020
|
|
|
68 |
WHEEL SHAFT
.
|
|
MSBP0PRO021
|
|
|
69 |
AC MOTOR ROTATION SHAFT-A
.
|
|
AC MOTOR ROTATION SHAFT-A
.
MSBP0PRO022
|
|
|
70 |
AC MOTOR ROTATION SHAFT-B
.
|
|
AC MOTOR ROTATION SHAFT-B
.
MSBP0PRO023
|
|
|
71 |
COIN CUHUTE RINK SHAFT A
.
|
|
COIN CUHUTE RINK SHAFT A
.
MSBP0PRO024
|
|
|
72 |
RARE CARD SBP V2
R05
|
|
MSBP0RFC001
|
|
|
73 |
TILT
.
|
|
MWIC0PAR100
|
|
|
74 |
LED CAP
10MM 투명
|
|
MWOL0PLA002
|
|
|
75 |
UNIT BEARING
SBPP204 조립후입고
|
|
UNIT BEARING
SBPP204 조립후입고
MZZZ0BEA089
|
|
|
76 |
BEARING
6000ZZ
|
|
MZZZ0BEA095
|
|
|
77 |
GEAR HEAD
K6G250C
|
|
MZZZ0GEA001
|
|
|
78 |
KEY ONLY 6001
2EA 1SET _WITH RING
|
|
KEY ONLY 6001
2EA 1SET _WITH RING
MZZZ0KEY014
|
|
|
79 |
KEY ONLY 7001
2EA 1SET_WITH RING
|
|
KEY ONLY 7001
2EA 1SET_WITH RING
MZZZ0KEY035
|
|
|
80 |
AC MOTOR 110V
K6IG6NU
|
|
MZZZ0MOT085
|
|
|
81 |
MOTOR
K6DG6N1
|
|
MZZZ0MOT086
|
|
|
82 |
AC MOTOR 220V
K6IG6NC CE
|
|
MZZZ0MOT111
|
|
|
83 |
LED CAP
Φ20_투명
|
|
MZZZ0PLA037
|
|
|
84 |
BUTTON LED HOUSING
|
|
MZZZ0PLA038
|
|
