1 |
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
|
|
PHOTO INT-1 PCB ASS'Y
STRIGHT_CIRCLE RAMA
ACIR0PCB011
|
|
|
2 |
AC INPUT ASS'Y
DAC-13H,WITH FUSE10A_2EA
|
|
AC INPUT ASS'Y
DAC-13H,WITH FUSE10A_2EA
AELE0FUS002
|
|
|
2.1 |
FUSE 10A
0218010.MXP 250V,10A,4PA
|
|
FUSE 10A
0218010.MXP 250V,10A,4PA
MELE0FUS018
|
|
|
2.2 |
AC INPUT
DAC-13H
|
|
MELE0SWI015
|
|
|
3 |
PRIZE DISPENSER ASS'Y
I-CUBE
|
|
PRIZE DISPENSER ASS'Y
I-CUBE
AICU0ASS003
|
|
|
3.1 |
MICRO SWITCH
GSMV16_51A2
|
|
MELE0MIC021
|
|
|
3.2 |
PRIZES/W3-1
I CUBE
|
|
MICU0HAN001
|
|
|
3.3 |
PRIZE DISPENSER MAIN BKT
.
|
|
PRIZE DISPENSER MAIN BKT
.
MICU0MEP009
|
|
|
3.4 |
PRIZE DISPENSER SCREW
ABS.
|
|
PRIZE DISPENSER SCREW
ABS.
MICU0PLA001
|
|
|
3.5 |
PRIZE DISPENSER BLOCK
ACETAL
|
|
PRIZE DISPENSER BLOCK
ACETAL
MICU0PLA002
|
|
|
3.6 |
BEARING
F688ZZ
|
|
MZZZ0BEA076
|
|
|
3.7 |
MOTOR
KWC-0025-3429G-0004
|
|
MOTOR
KWC-0025-3429G-0004
MZZZ0MOT063
|
|
|
4 |
AC MOTOR PCB ASS'Y
I-CUBE
|
|
AC MOTOR PCB ASS'Y
I-CUBE
AICU0PCB007
|
|
|
5 |
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
|
|
ATX JOIN 2 OZ PCB ASS'Y
SPONGE BOB PINEAPPLE
ASBP0PCB010
|
|
|
6 |
ARROW SHAFT BEARING HOUSING ASS'Y
.
|
|
ARROW SHAFT BEARING HOUSING ASS'Y
.
ASHS0ASS001
|
|
|
7 |
ARROW BODY MAIN ASS'Y
STD
|
|
ARROW BODY MAIN ASS'Y
STD
ASHS0ASS004
|
|
|
7.1 |
ARROW BODY MOLD BKT
STD
|
|
MSHS0MEP082
|
|
|
7.2 |
ARROW BODY SHEET
.
|
|
MSHS0SHE011
|
|
|
7.3 |
ARROW BODY ACRYL
BASIC 사출
|
|
ARROW BODY ACRYL
BASIC 사출
MSSS0PRO013
|
|
|
8 |
ARROW BODY MAIN ASS'Y
1H
|
|
ASHS0ASS005
|
|
|
8.1 |
ARROW BODY BASE BKT_SKILL
SKILL용
|
|
ARROW BODY BASE BKT_SKILL
SKILL용
MSHS0MEP092
|
|
|
8.2 |
ARROW BODY MAIN_1H SKILL
.
|
|
ARROW BODY MAIN_1H SKILL
.
MSHS0PRO005
|
|
|
8.3 |
ARROW BODY SHEET
.
|
|
MSHS0SHE011
|
|
|
9 |
ARROW BODY MAIN ASS'Y
3H
|
|
ASHS0ASS006
|
|
|
9.1 |
ARROW BODY BASE BKT_SKILL
SKILL용
|
|
ARROW BODY BASE BKT_SKILL
SKILL용
MSHS0MEP092
|
|
|
9.2 |
ARROW BODY MAIN_3H SKILL
3H용
|
|
ARROW BODY MAIN_3H SKILL
3H용
MSHS0PRO006
|
|
|
9.3 |
ARROW BODY SHEET
.
|
|
MSHS0SHE011
|
|
|
10 |
TARGET SIDE LED PCB ASS'Y
BGR
|
|
TARGET SIDE LED PCB ASS'Y
BGR
ASHS0PCB001
|
|
|
11 |
RGB_BUTTON_LED PCB ASS'Y
CODE CHANGE AZZZ0PCB209
|
|
RGB_BUTTON_LED PCB ASS'Y
CODE CHANGE AZZZ0PCB209
ASHS0PCB002
|
|
|
12 |
BILLBOARD LIGHTING PCB-A
.
|
|
BILLBOARD LIGHTING PCB-A
.
ASHS0PCB006
|
|
|
13 |
BILLBOARD LIGHTING PCB-B
.
|
|
BILLBOARD LIGHTING PCB-B
.
ASHS0PCB007
|
|
|
14 |
BILLBOARD LIGHTING PCB-C
.
|
|
BILLBOARD LIGHTING PCB-C
.
ASHS0PCB008
|
|
|
15 |
ARROW SHAFT MAIN ASS'Y
.
|
|
ASSS0ASS002
|
|
|
16 |
FND PCB ASS'Y
SUSHI PARTY
|
|
FND PCB ASS'Y
SUSHI PARTY
ASUP0PCB004
|
|
|
17 |
CREDIT FND PCB ASS'Y
WINNERS CUBE DX
|
|
CREDIT FND PCB ASS'Y
WINNERS CUBE DX
AWID0PCB004
|
|
|
18 |
COIN BOX ASS WITH 6001
SMALL 200*198*107
|
|
COIN BOX ASS WITH 6001
SMALL 200*198*107
AZZZ0ASS002
|
|
|
18.1 |
COIN BOX SMALL
200*198*107 BLACK
|
|
COIN BOX SMALL
200*198*107 BLACK
MDRE0PLA007
|
|
|
18.2 |
KEY ASS'Y 6001
6001 키뭉치만
|
|
MZZZ0KEY075
|
|
|
19 |
BUTTON ASS'Y
CL-2020 65 WITH LED
|
|
BUTTON ASS'Y
CL-2020 65 WITH LED
AZZZ0BUT009
|
|
|
19.1 |
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
|
|
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
MELE0MIC013
|
|
|
19.2 |
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
|
|
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
MZZZ0BUT101
|
|
|
19.3 |
HOLDER ASS'Y
LED포함
|
|
MZZZ0BUT103
|
|
|
20 |
LED BAR 12V ASS'Y
460MM
|
|
AZZZ0PCB124
|
|
|
21 |
LED BAR 12V ASS'Y
910MM
|
|
AZZZ0PCB128
|
|
|
22 |
MAIN PCB ASS'Y WITH CPU_SOUND
CODE CHANGE AZZZ0PCB245
|
|
MAIN PCB ASS'Y WITH CPU_SOUND
CODE CHANGE AZZZ0PCB245
AZZZ0PCB146
|
|
|
22.1 |
CPU PCB C ASS'Y
SCU_ICU_MAG_SM1,3H_SU1,3H_MAG
|
|
CPU PCB C ASS'Y
SCU_ICU_MAG_SM1,3H_SU1,3H_MAG
ASHS0PCB004
|
|
|
22.2 |
SOUND ROM PCB ASS'Y
SHOOTING STAR
|
|
SOUND ROM PCB ASS'Y
SHOOTING STAR
ASHS0PCB005
|
|
|
22.3 |
MAIN PCB ASS'Y
CODE CHANGE AZZZ0PCB256
|
|
MAIN PCB ASS'Y
CODE CHANGE AZZZ0PCB256
AZZZ0PCB138
|
|
|
23 |
RGB_BUTTON_LED PCB ASS'Y V2
1K
|
|
RGB_BUTTON_LED PCB ASS'Y V2
1K
AZZZ0PCB209
|
|
|
23.1 |
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
|
|
MICRO SWITCH_FOR BUTTON
SZM-V16-FA-63(200G)
MELE0MIC013
|
|
|
23.2 |
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
|
|
BUTTON ASS'Y _ NO SWITCH
CL-2020 65 TYPE LED
MZZZ0BUT101
|
|
|
23.3 |
HOLDER ASS'Y
LED포함
|
|
MZZZ0BUT103
|
|
|
24 |
HAND BOLT
6*35
|
|
BHAB0060002
|
|
|
25 |
PLUG CUSHION RUBBER
공진 [KD-96R-9] 6MM
|
|
PLUG CUSHION RUBBER
공진 [KD-96R-9] 6MM
MCIR0RUB001
|
|
|
26 |
LED STICK BAR BRK
12MM 90도
|
|
LED STICK BAR BRK
12MM 90도
MELE0000022
|
|
|
27 |
FERRITE CORE
RU(TU)1132
|
|
MELE0FER003
|
|
|
28 |
MICRO SWITCH-S
GSMS5_41TLA(구3142)
|
|
MICRO SWITCH-S
GSMS5_41TLA(구3142)
MELE0MIC003
|
|
|
29 |
MICRO SWITCH
GSMV16_31A1
|
|
MELE0MIC022
|
|
|
30 |
NOISE FILTER
RNS-2010
|
|
MELE0NOI009
|
|
|
31 |
ATX POWER SUPPLY
CODE CHANGE MELE0SMP149
|
|
ATX POWER SUPPLY
CODE CHANGE MELE0SMP149
MELE0SMP099
|
|
|
32 |
ROCKER SWITCH
R595KDF
|
|
MELE0SWI021
|
|
|
33 |
TERMINAL BLOCK
250V 10P UL_CE
|
|
TERMINAL BLOCK
250V 10P UL_CE
MELE0TEB003
|
|
|
34 |
PRIZE DISPENSER PUSH BKT GUIDE
ACETAL
|
|
PRIZE DISPENSER PUSH BKT GUIDE
ACETAL
MICU0PLA003
|
|
|
35 |
PRIZE DISPENSER GUIDE BLOCK
.
|
|
PRIZE DISPENSER GUIDE BLOCK
.
MICU0PLA004
|
|
|
36 |
Z MOTOR PART GUIDE SHAFT
8*20
|
|
Z MOTOR PART GUIDE SHAFT
8*20
MICU0PRO008
|
|
|
37 |
PRIZE INNER DOOR BUSHING
15*10
|
|
PRIZE INNER DOOR BUSHING
15*10
MICU0PRO012
|
|
|
38 |
PRIZE INNER DOOR ROTATE BUSHING
15*6
|
|
PRIZE INNER DOOR ROTATE BUSHING
15*6
MICU0PRO013
|
|
|
39 |
ATTENTION OPERATORS SHEET
.
|
|
ATTENTION OPERATORS SHEET
.
MICU0SHE027
|
|
|
40 |
PRIZE DISPENSER LOGO ACRYL
SUPER STAR
|
|
PRIZE DISPENSER LOGO ACRYL
SUPER STAR
MSHS0ACR010
|
|
|
41 |
PRIZE DISPENSER LOGO ACRYL
SUPER STAR S
|
|
PRIZE DISPENSER LOGO ACRYL
SUPER STAR S
MSHS0ACR017
|
|
|
42 |
FRONT DOOR GLASS
930*1065*8T
|
|
FRONT DOOR GLASS
930*1065*8T
MSHS0GLA002
|
|
|
43 |
TARGET BASE SPACER
.
|
|
MSHS0PRO003
|
|
|
44 |
TARGET DISPLAY FIX BAR
.
|
|
MSHS0PRO004
|
|
|
45 |
PRIZE SIZE SHEET
SUPER STAR
|
|
PRIZE SIZE SHEET
SUPER STAR
MSHS0SHE026
|
|
|
46 |
TIMMING BELT PULLEY-B
P16S5M 33F
|
|
TIMMING BELT PULLEY-B
P16S5M 33F
MSSS0PRO004
|
|
|
47 |
Z MOTOR GEAR ASS'Y
.
|
|
MSSS0PRO006
|
|
|
48 |
BEARING GUIDE SHAFT ASS'Y
.
|
|
BEARING GUIDE SHAFT ASS'Y
.
MSSS0PRO009
|
|
|
49 |
TARGET DISPLAY ACRYL
.
|
|
MSSS0PRO012
|
|
|
50 |
TILT
.
|
|
MWIC0PAR100
|
|
|
51 |
Z MOTOR PART TENSION SPRING
.
|
|
Z MOTOR PART TENSION SPRING
.
MWID0SPR001
|
|
|
52 |
COVER BUSHING
판금용엣지_1.2T 27CM
|
|
COVER BUSHING
판금용엣지_1.2T 27CM
MZZZ0000481
|
|
|
53 |
LED CAP
20MM 투명 LED
|
|
MZZZ0000521
|
|
|
54 |
BEARING
626ZZ
|
|
MZZZ0BEA087
|
|
|
55 |
TIMMING BELT
BS3M-339 15MM
|
|
TIMMING BELT
BS3M-339 15MM
MZZZ0BEL023
|
|
|
56 |
COIN SELECTOR
TW-333_WITHOUT FND
|
|
COIN SELECTOR
TW-333_WITHOUT FND
MZZZ0COS045
|
|
|
57 |
COUNTER
OA127CL W/2P CONNECTOR_20CM WIRE
|
|
COUNTER
OA127CL W/2P CONNECTOR_20CM WIRE
MZZZ0COU002
|
|
|
58 |
KEY ONLY 6001
2EA 1SET _WITH RING
|
|
KEY ONLY 6001
2EA 1SET _WITH RING
MZZZ0KEY014
|
|
|
59 |
KEY ONLY 7001
2EA 1SET_WITH RING
|
|
KEY ONLY 7001
2EA 1SET_WITH RING
MZZZ0KEY035
|
|
|
60 |
KEY ASS'Y 7001
7001 키뭉치만
|
|
MZZZ0KEY076
|
|
|
61 |
STEPPING MOTOR
4S56Q-08576S
|
|
STEPPING MOTOR
4S56Q-08576S
MZZZ0MOT064
|
|
|
62 |
MOTOR
KGE-3429-050,1/452(10 RPM)
|
|
MOTOR
KGE-3429-050,1/452(10 RPM)
MZZZ0MOT082
|
|
|
63 |
BUTTON LED HOUSING
|
|
MZZZ0PLA038
|
|
|
64 |
SPEAKER
MID 4.5"+TW1/2" 8Ω W-C-100 F BK
|
|
SPEAKER
MID 4.5"+TW1/2" 8Ω W-C-100 F BK
MZZZ0SPE021
|
|
|
65 |
SSP R PIN
12
|
|
MZZZ0SPR030
|
|
|
66 |
WARNING STICKER (ETL 유리 파손)
110*35
|
|
WARNING STICKER (ETL 유리 파손)
110*35
MZZZ0STI088
|
|
|
67 |
NOTICE STICKER
100*35 10초후전원ON
|
|
NOTICE STICKER
100*35 10초후전원ON
MZZZ0STI092
|
|
|
68 |
CAUTION STICKER-B(WATCH YOUR HEAD OR HAN
160*35 SS2 11SHE삽입
|
|
CAUTION STICKER-B(WATCH YOUR HEAD OR HAN
160*35 SS2 11SHE삽입
MZZZ0STI094
|
|
|
69 |
NOTICE(DON'T SHAKE)
.
|
|
MZZZ0STI098
|
|
